Cisco 350-701 Dumps Questions Answers

 The monitoring agent uses the RTP (Real-time Transport Protocol) performance metric to collect and output packet loss and jitter information. RTP is a network protocol used for delivering audio and video over IP networks. It provides mechanisms for timestamping, sequence numbering, and delivery monitoring, which allow for the measurement of packet loss and jitter. RTP is specifically designed for real-time multimedia streaming applications, which are more sensitive to changes in the transmission characteristics of data networks than other applications. Therefore, RTP performance is a suitable metric for monitoring and collecting packet loss and jitter information.

The other options are not directly related to measuring packet loss and jitter. TCP (Transmission Control Protocol) is a transport protocol that ensures reliable and ordered delivery of data, but it is not typically used for real-time multimedia applications. WSAv (Web Security Virtual Appliance) is a Cisco solution for web security, but it does not measure packet loss and jitter. AVC (Application Visibility and Control) is a technology that monitors and controls network applications, but it does not focus on packet loss and jitter. References :=

Measuring Delay, Jitter, and Packet Loss with Cisco IOS SAA and RTTMON1

Implementing and Operating Cisco Security Core Technologies (SCOR) v1.02

Cisco 350-701: Which metric used by monitoring agent to collect and output packet loss and jitter information?

 A SYN flood is a type of denial-of-service (DoS) attack that exploits the TCP three-way handshake process to exhaust the resources of a target server. The attacker sends a large number of SYN packets to the target server, each with a spoofed source IP address. The target server allocates resources for each incoming SYN packet and responds with a SYN-ACK packet to the spoofed address. However, the spoofed address never sends back the final ACK packet to complete the connection, leaving the target server with many half-open connections that eventually fill up its connection table. This prevents the target server from accepting new legitimate connections and causes service disruption123 References: 1: Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0 course overview 2: SYN Flood Explained. How to Prevent this Attack from Taking over your … 3: What is a SYN flood attack? | Cloudflare

 The management port on Cisco FMC is used to establish a secure connection with the managed Cisco FTD devices. If the default management port (8305) conflicts with other communications on the network, it must be changed on both the Cisco FMC and the Cisco FTD devices. This cannot be done automatically by the Cisco FMC, as it would lose connectivity with the devices. Therefore, the administrator must manually change the management port on the Cisco FMC and all the managed Cisco FTD devices using the command line interface (CLI). The steps to change the management port are as follows:

Log into the CLI of the Cisco FMC and the Cisco FTD devices using a console connection or SSH.

Enter the configure network {ipv4 | ipv6} manual ip_address netmask data-interfaces command to change the management port on the Cisco FMC. For example, configure network ipv4 manual 10.10.10.10 255.255.255.0 data-interfaces changes the management port to 10.10.10.10/24.

Enter the configure network {ipv4 | ipv6} manual ip_address netmask gateway management-only command to change the management port on the Cisco FTD devices. For example, configure network ipv4 manual 10.10.10.11 255.255.255.0 10.10.10.10 management-only changes the management port to 10.10.10.11/24 and sets the gateway to the Cisco FMC’s management port.

Save the configuration and restart the Cisco FMC and the Cisco FTD devices.

Verify the connectivity between the Cisco FMC and the Cisco FTD devices using the show managers command on the Cisco FTD devices and the show devices command on the Cisco FMC.

References :=

Firepower Management Center Device Configuration Guide, 7.1 - Device Management

Change management port fmc 1600 - Cisco Community

Solved: FMC 2120 FTD Management Only Port - Cisco Community

Change the FMC Access Interface from Management to Data
