In an EVPN-VXLAN Edge-Routed Bridging (ERB) architecture, also known as a collapsed fabric, the Layer 3 default gateway functionality is moved from the core/spine layer down to the edge (the leaf or distribution layer).

Anycast Gateways: To support seamless host mobility and redundancy, multiple distribution/leaf switches are configured with the same anycast IP address and MAC address on their IRB interfaces for a given VLAN. This allows a host to move between different switches without needing to update its default gateway configuration or ARP cache.

Distributed Routing: Routing occurs locally at the edge (distribution layer). Traffic destined for a different subnet is routed by the first switch it hits (the ingress leaf), rather than being backhauled to a central core router.

Symmetric vs. Asymmetric IRB: Junos OS 24.4 supports both models, but the ERB design typically utilizes symmetric routing for better scalability, where each leaf only needs to know the routes for its locally connected VNIs and uses a transit VNI for inter-subnet communication.

Option A is incorrect because while unique IPs can be used (Method 1 in some docs), the defining characteristic of an efficient ERB design is the use of shared Anycast IPs for the gateway. Option C describes a Centrally-Routed Bridging (CRB) design, not ERB.

The exhibit shows the output of the show poe interface command on a Juniper switch.

VTEP Power Capabilities (Statement D): The exhibit shows the Pair/Mode as 2P/AT, which refers to the IEEE 802.3at (PoE+) standard. Under this standard, a switch can supply up to 30 W of power per port to attached devices (PDs). * Dynamic Learning (Statement C): Looking at the Max power column for port ge-0/0/0, it shows 19.5W(L). The (L) indicator signifies that the power has been dynamically learned (negotiated) via LLDP or hardware classification, rather than being statically configured by an administrator. Additionally, it has identified the device as Class 4, which is a standard dynamic classification for PoE+ devices.

Why others are incorrect: Statement A (60 W) refers to the 802.3bt (PoE++) standard, which is not indicated here. Statement B is incorrect because the "(L)" confirms the configuration is not static.

In standard BGP operations, a router typically selects only one "best path" for a given destination prefix and installs that single path into the forwarding table. To utilize multiple paths for traffic forwarding (load-balancing), specific multipath features must be enabled.

BGP Multipath: This feature allows a router to install multiple equal-cost paths into the routing and forwarding tables. However, by default, BGP multipath requires that all candidate paths have the same neighboring Autonomous System (AS).

Multipath Multiple-AS (Option B): In the exhibit, R1 is receiving routes from ISP A (AS 65501) and ISP B (AS 65502). Since these are two different neighboring ASs, the standard multipath feature is not sufficient. You must use the multipath multiple-as statement under the BGP group or neighbor hierarchy. This tells Junos to consider paths as equal even if they originate from different neighboring ASs, provided all other BGP path selection attributes (Local Preference, AS Path length, Origin, MED, etc.) are identical.

Why other options are incorrect: * Option A (multihop) is used for peering with routers that are not directly connected.

Option C (prefix limit) is a security and stability feature to limit the number of prefixes received from a neighbor.

Option D (damping) is used to penalize unstable, "flapping" routes to prevent constant routing table churn.

Configuration Example for Junos OS 24.4: To implement this on R1, you would use the following configuration:

set protocols bgp group multipath multiple-as
