4A0-220 Nokia GMPLS-Controlled Optical Networks Questions and Answers

GMPLS-enabled nodes use routing protocols, such as OSPF-TE or ISIS-TE, to exchange information about the topology and the state of the links in the network12. This information includes the link attributes, such as bandwidth, wavelength, protection, and shared risk link groups (SRLGs)3. The state of each link indicates whether it is up or down, available or reserved, and so on. This information is used by GMPLS-enabled nodes to compute feasible paths for LSPs and to avoid routing loops or conflicts. The bandwidth and the frequency of each client path are not present in every GMPLS-enabled node, but only in the ingress and egress nodes that initiate and terminate the LSPs. The list of LSPs created in the entire network is also not present in every GMPLS-enabled node, but only in the nodes that are involved in the LSPs or that maintain a global view of the network. References:

• 1: GMPLS - Nokia
• 2: Generalized Multi-Protocol Label Switching - Wikipedia
• 3: Nokia GMPLS-controlled Optical Networks Course | Nokia

A network with ROADM GMPLS nodes and optical transponder connections could have both L0 and L1 restoration capabilities. L0 restoration refers to the ability of the network to recover from failures at the optical layer, such as fiber cuts or node failures, by rerouting the affected LSPs to alternative paths at the same layer. L0 restoration can be achieved by using GMPLS signaling protocols, such as RSVP-TE or CR-LDP, to establish backup LSPs in advance or on demand. L0 restoration can provide fast recovery times and high availability for optical services34. L1 restoration refers to the ability of the network to recover from failures at the sub-wavelength layer, such as transponder failures or wavelength unavailability, by rerouting the affected LSPs to alternative paths at a higher layer. L1 restoration can be achieved by using GMPLS routing protocols, such as OSPF-TE or ISIS-TE, to advertise the sub-wavelength information and availability to other nodes in the network. L1 restoration can provide more flexibility and efficiency for sub-wavelength services56. References:

• 3: GMPLS - Nokia
• 4: Generalized Multi-Protocol Label Switching - Wikipedia
• 5: Sub-Wavelength Switching - Nokia
• 6: Sub-Wavelength Switching in Optical Networks - IEEE Xplore

The equipment vendor is not a parameter that is considered when restoring an LSP. Restoration is the process of re-establishing an LSP after a failure by using an alternative path that meets the same constraints as the original LSP. The parameters that are considered when restoring an LSP include coloring, reservation priority, maximum latency, bandwidth, protection type, and other QoS attributes. The equipment vendor does not affect the restoration process as long as the nodes support GMPLS protocols and interoperate with each other. References : RFC 4427 - Recovery (Protection and Restoration) Terminology for Generalized Multi-Protocol Label Switching (GMPLS), [Nokia GMPLS-controlled Optical Networks Course | Nokia]

The GMRE functionality is guaranteed in Nokia equipment by controller redundancy. The controller is the hardware component that runs the GMPLS software and controls the switching fabric of the node. Each node has two controllers, one active and one standby, that synchronize their states and databases. If the active controller fails, the standby controller takes over and ensures the continuity of the GMRE functionality. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, 1830 Photonic Service Switch (PSS) | Nokia

The SNC state is a parameter that indicates the status of a resource in a GMPLS network. A resource can be a link, a wavelength, a timeslot, or a fiber. The SNC state can have different values, such as N, n, P, p, R, r, and so on. Each value has a specific meaning and implication for the resource and the LSP that uses it. The SNC state of lower case “n” means that the resource is the nominal resource on a TE-link that is notin use. A nominal resource is the default or preferred resource that is assigned to an LSP when it is created. A TE-link is a logical link that represents a set of resources that share the same attributes and constraints. A TE-link can have multiple resources, such as wavelengths or timeslots, but only one of them can be the nominal resource. If an LSP is using a resource other than the nominal resource on a TE-link, it means that the LSP has been rerouted or switched due to a failure or a constraint violation. In this case, the SNC state of the nominal resource will be “n”, indicating that it is not in use by any LSP12. References:

• 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
• 2: Nokia Network Functions Manager for Transport User Guide | Nokia

To configure the Trail template in NFM-T for an Uplink board (such as 2UC400) in an MRN network with LO and LI restoration capabilities, you need to check the Logical Link box, set the Port Type to Unterminated, check the ASON Routed box, and uncheck the ASON Tunnel box. This configuration allows you to create a logical link between two Uplink boards that can be used for LO or LI restoration. The logical link is not terminated at the Uplink board, but at the OTU board. The ASON Routed option enables the GMPLS control plane for the logical link, while the ASON Tunnel option is not applicable for Uplink boards. References : Nokia Advanced Optical Network Management with NFM-T Course | Nokia, Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms - NATO

Quality of Service (QoS) in GMPLS is the ability to set constraints such as latency and priority for different kinds of services. This means that GMPLS can allocate network resources according to the specific requirements of each service, such as voice, video, or data. For example, a voice service may need low latency and high priority, while a data service may need high bandwidth and low priority. GMPLS can use Traffic Engineering (TE) extensions to OSPF and RSVP protocols to advertise and reserve network resources based on QoS parameters. References : [Nokia GMPLS-controlled Optical Networks Course | Nokia], [Quality of Service - Nokia]

The GMRE node address is the IP address for communication between network elements (NEs) in a GMPLS-controlled optical network. The GMRE node address is also known as the GMRE loopback address or the GMPLS node IP. It is used by GMPLS protocols such as LMP and RSVP to identify and communicate with other GMRE nodes. The GMRE node address is configured on each NE and is advertised by OSPF-TE to other nodes in the same area. References : Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms - NATO, 1830 PSS Identifiers

The SNC Nominal Route is the default or preferred route that is assigned to an LSP when it is created. The SNC Nominal Route is determined by the constraints that are specified by the user during the LSP creation process, such as cost, SRLG, color, bandwidth, protection, and regeneration. The user can modify the SNC Nominal Route in NFM-T by using the Constraint Wizard, which is a tool that allows the user to change the constraints for an existing LSP. The Constraint Wizard will then compute a new SNC Nominal Route based on the modified constraints and update the LSP accordingly34. References:

• 3: Nokia GMPLS-controlled Optical Networks Course | Nokia
• 4: Nokia Network Functions Manager for Transport User Guide | Nokia
