2V0-41.23 VMware NSX 4.x Professional Questions and Answers

https://docs.vmware.com/jp/VMware-NSX/4.1/installation/GUID-B7E7371E-A9F6-4880-B184-E00A62C0C818.html

The sequence of commands that could be used to check the BGP connection status between the Tier-O Gateway and the upstream physical router on NSX Edge node is get gateways, vrf , get bgp neighbor. These commands can be executed on the NSX Edge node CLI after logging in as admin6. The first command, get gateways, displays the list of logical routers (gateways) configured on the Edge node, along with their IDs and VRF numbers7. The second command, vrf , switches to the VRF context of the desired Tier-O Gateway, where is the VRF number obtained from the previous command7. The third command, get bgp neighbor, displays the BGP neighbor summary for the selected VRF, including the neighbor IP address, AS number, state, uptime, and prefixes received8. The other options are incorrect because they either use invalid or incomplete commands or do not switch to the correct VRF context. References: NSX-T Command-Line Interface Reference, NSX Edge Node CLI Commands, Troubleshooting BGP on NSX-T Edge Nodes

The correct answer is to enable the option All LB VIP Routes on the Tier-1 gateway route advertisement settings. This option allows the Tier-1 gateway to advertise the NSX Advanced Load Balancer LB VIP routes to the Tier-0 gateway and other peer routers, so that the end users can reach the production website by using the VIP address1. The other options are not relevant for this scenario.

To mark the correct answer by clicking on the image, you can click on the toggle switch next to All LB VIP Routes to turn it on. The switch should change from gray to blue, indicating that the option is enabled. See the image below for reference:

According to the VMware Knowledge Base article 1, the CLI command to set the log level of the NSX Manager to debug mode is set service manager logging-level debug. This command can be used when the NSX UI is inaccessible or when troubleshooting issues with the NSX Manager1. The other commands are incorrect because they either use a wrong syntax or a wrong service name. The NSX Manager service name is manager, not nsx-manager2. The log level parameter is logging-level, not log-level3.

https://kb.vmware.com/s/article/55868

https://docs.vmware.com/en/VMware-NSX/4.1/administration/GUID-69DF70C2-1769-4858-97E7-B757CAED08F0.html#:~:text=On%20the%20north%2Dsouth%20traffic,Guest%20Introspection%20(GI)%20platform .

The main components on the edge node for north-south malware prevention perform the following functions:

• IDS/IPS engine: Extracts files and relays events and data to the security hub

North-south malware prevention uses the file extraction features of the IDS/IPS engine that runs on NSX Edge for north-south traffic.

• Security hub: Collects file events, obtains verdicts for known files, sends files for local and cloud-based analysis, and sends information to the security analyzer

• RAPID: Provides local analysis of the file

• ASDS Cache: Caches reputation and verdicts of known files

VMware NSX is a portfolio of networking and security solutions that enables consistent policy, operations, and automation across multiple cloud environments1

The VMware NSX portfolio includes the following solutions:

• VMware NSX Data Center: A platform for data center network virtualization and security that delivers a complete L2-L7 networking stack and overlay services for any workload1
• VMware NSX Cloud: A service that extends consistent networking and security to public clouds such as AWS and Azure1
• VMware NSX Advanced Load Balancer: A solution that provides load balancing, web application firewall, analytics, and monitoring for applications across any cloud12
• VMware NSX Distributed IDS/IPS: A feature that provides distributed intrusion detection and prevention for workloads across any cloud12
• VMware NSX Intelligence: A service that provides planning, observability, and intelligence for network and micro-segmentation1
• VMware NSX Federation: A capability that enables multi-site networking and security management with consistent policy and operational state synchronization1
• VMware NSX Service Mesh: A service that connects, secures, and monitors microservices across multiple clusters and clouds1
• VMware NSX for Horizon: A solution that delivers secure desktops and applications across any device, location, or network1
• VMware NSX for vSphere: A solution that provides network agility and security for vSphere environments with a built-in console in vCenter1
• VMware NSX-T Data Center: A platform for cloud-native applications that supports containers, Kubernetes, bare metal hosts, and multi-hypervisor environments1

VMware Tanzu Kubernetes Grid and VMware Tanzu Kubernetes Cluster are not part of the VMware NSX portfolio. They are solutions for running Kubernetes clusters on any cloud3

VMware Aria Automation is not a real product name. It is a fictional name that does not exist in the VMware portfolio.

https://blogs.vmware.com/networkvirtualization/2020/01/nsx-hero.html/

The RouterLink port is automatically created when a Tier-1 Gateway is connected with a Tier-0 Gateway from the NSX UI1. The RouterLink port is a logical interface that is assigned an IP address and is associated with a physical or virtual interface. The RouterLink port acts as an end point of the IPSec tunnel and routes traffic between the Tier-1 Gateway and the Tier-0 Gateway2. The other options are incorrect because they involve manual creation of logical switches or segments, which are not required for RouterLink port creation. References: Configure NSX for Virtual Networking from vSphere Client, Virtual Private Network (VPN)

https://docs.vmware.com/jp/VMware-NSX/4.0/administration/GUID-3F163DEE-1EE6-4D80-BEBF-8D109FDB577C.html

According to the web search results, network segmentation is a feature of NSX that improves the security of today’s modern workloads by preventing lateral movement. Lateral movement is a technique used by attackers to move from one compromised system to another within a network, exploiting vulnerabilities or credentials . Network segmentation prevents lateral movement by dividing a network into smaller segments or zones, each with its own security policies and controls. This way, if one segment is compromised, the attacker cannot access other segments or resources . NSX enables network segmentation by using micro-segmentation, which applies granular firewall rules at the virtual machine level, regardless of the physical network topology .

According to the VMware NSX Documentation1, a segment is mapped to a unique Geneve segment that is distributed across the ESXi hosts in a transport zone. The Geneve segment uses a virtual network identifier (VNI) as an overlay network identifier. The VNI ID can be used to identify overlay segments in an NSX environment if troubleshooting is required.

The two interfaces that will be used for ingress traffic on the Edge node supporting a Single Tier topology are:

• B. Tier-0 Uplink interface
• C. Downlink Interface for the Tier-0 DR

The Tier-0 Uplink interface is the interface that connects the Tier-0 gateway to the external network. It is used to receive traffic from the physical router or switch that is the next hop for the Tier-0 gateway. The Tier-0 Uplink interface can be configured with a static IP address or use BGP to exchange routes with the external network.

The Downlink Interface for the Tier-0 DR is the interface that connects the Tier-0 gateway to the workload segments. It is used to receive traffic from the VMs or containers that are attached to the segments. The Downlink Interface for the Tier-0 DR is a logical interface (LIF) that is distributed across all transport nodes that host the segments. The Downlink Interface for the Tier-0 DR has an IP address that acts as the default gateway for the VMs or containers on the segments.

According to the VMware NSX 4.x Professional documents and tutorials, an NSX Manager is a standalone appliance that hosts the API services, the management plane, control plane, and policy management. The NSX Manager has three built-in roles: policy, manager, and controller2. The policy role handles the declarative configuration of the system and translates it into desired state for the manager role. The manager role receives and validates the configuration from the policy role and stores it in a distributed persistent database. The manager role also publishes the configuration to the central control plane. The controller role implements the central control plane that computes the network state based on the configuration and topology information3. The other roles (master, cloud, and zookeeper) are not valid NSX Manager roles.

According to the VMware NSX Documentation, these are three of the capabilities of Network Topology, which is a graphical representation of your network infrastructure in NSX:

• Display how the different NSX components are interconnected: You can use Network Topology to view how your segments, gateways, routers, firewalls, load balancers, VPNs, and other NSX components are connected and configured in your network.
• Display the uplink configured on the Tier-0 Gateways: You can use Network Topology to view the uplink interface and segment that connect your tier-0 gateways to your physical network. You can also view the VLAN ID and IP address of the uplink interface.
• Display the VMs connected to Segments: You can use Network Topology to view the VMs that are attached to your segments. You can also view the IP address and MAC address of each VM.

https://docs.vmware.com/en/VMware-NSX/4.0/administration/GUID-A75B2553-7595-40B9-A902-854941BB06FD.html

The insertion point for East-West network introspection is the Guest VM vNIC. Network introspection is a service insertion feature that allows third-party network services to be integrated with NSX. Network introspection enables traffic redirection from the Guest VM vNIC to a service virtual machine (SVM) that runs the partner service. The SVM can then inspect, monitor, or modify the traffic before sending it back to the original destination1. The other options are incorrect because they are not the insertion points for East-West network introspection. The Tier-0 router is used for North-South routing and network services. The partner SVM is the service virtual machine that runs the partner service, not the insertion point. The host physical NIC is not involved in network introspection. References: Network Introspection Settings

NSX Global Manager is a feature of NSX that allows managing multiple NSX domains across different sites or clouds from a single pane of glass. NSX Global Manager supports Federation, which is a capability that enables synchronizing configuration and policy across multiple NSX domains. Federation has many benefits such as simplifying operations, improving resiliency, and enabling disaster recovery.

The only supported mode in NSX Global Manager when using Federation is Policy mode. Policy mode means that NSX Global Manager acts as a policy manager that defines and distributes global policies to local NSX managers in different domains. Policy mode also allows local NSX managers to have their own local policies that can override or merge with global policies.

https://docs.vmware.com/en/VMware-NSX/4.0/administration/GUID-29998FC5-C1AB-40BC-B669-6E8E9937F345.html

Route-based VPN is a VPN type that uses Virtual Tunnel interfaces (VTI) to establish IPSec tunnels between an NSX Edge node and remote sites2. A VTI is a logical interface that is assigned an IP address and is associated with a physical or virtual interface. The VTI acts as an end point of the IPSec tunnel and routes traffic between the NSX Edge node and the remote site2. Route & SSL based VPNs, Policy & Route based VPNs, and SSL-based VPN are not VPN types that use VTI. References: Virtual Private Network (VPN)

According to the VMware NSX Documentation, these are two NAT rule types that are supported for a tier-0 gateway configured in active-standby high availability mode. NAT stands for Network Address Translation and is a feature that allows you to modify the source or destination IP address of a packet as it passes through a gateway.

• Destination NAT: This rule type allows you to change the destination IP address of a packet from an external IP address to an internal IP address. You can use this rule type to provide access to your internal servers from external networks using public IP addresses.
• Source NAT: This rule type allows you to change the source IP address of a packet from an internal IP address to an external IP address. You can use this rule type to provide access to external networks from your internal servers using public IP addresses.

The following L2 VPN clients are recommended:

1. NSX Managed NSX Edge in a separate NSX Managed environment.

• Overlay and VLAN segments can be extended.

2. Autonomous Edge:

• Enables L2 VPN access from a non-a NSX environment to NSX environments.

• Deployed by using an OVF file on a host that is not managed by NSX.

• Only VLAN segments can be extended.

According to the VMware NSX Documentation, a non-preemptive failover policy means that the original failed node will not become the active node upon recovery, unless the current active node fails again. This policy can help avoid unnecessary failovers and ensure stability.

The other options are either incorrect or not available for this configuration. Preemptive is the opposite of non-preemptive, meaning that the original failed node will become the active node upon recovery, if it has a higher priority than the current active node. Enable Preemptive and Disable Preemptive are not valid options for the failover policy, as the failover policy is a drop-down menu that only has two choices: Preemptive and Non-Preemptive.

The CLI command on NSX Manager and NSX Edge that is used to change NTP settings is set ntp-server. This command allows the user to configure one or more NTP servers for time synchronization12. The other options are incorrect because they are not valid CLI commands for changing NTP settings. The get timezone and set timezone commands are used to display and configure the timezone of the system1. The get time-server command is used to display the current time server configuration1. There are no CLI commands for using RADIUS or BootP for NTP settings. References: NSX-T Command-Line Interface Reference, vSphere ESXi 7.0 U3 and later versions NTP configuration steps

When deploying an NSX Edge Transport Node, two valid IP address assignment options that should be specified for the TEP IP addresses are Use an IP Pool and Use a Static IP List. These options allow the user to assign TEP IP addresses from a predefined range of IP addresses or a manually entered list of IP addresses, respectively345. The other options are incorrect because they are not supported methods for assigning TEP IP addresses. There is no option to use a DHCP server, RADIUS, or BootP for TEP IP address assignment in NSX-T345. References: NSX-T Edge TEP networking options, Multi-TEP High Availability, Create an IP Pool for Host Tunnel Endpoint IP Addresses

To configure a firewall rule based on the domain name of a specific application, the administrator needs to use the Profile field in a distributed firewall rule. The Profile field allows the administrator to select a context profile that contains one or more attributes for filtering traffic. One of the attributes that can be used is Domain (FQDN) Name, which specifies the fully qualified domain name of the application. For example, if the administrator wants to filter traffic to *.office365.com, they can create a context profile with the Domain (FQDN) Name attribute set to *.office365.com and use it in the Profile field of the firewall rule.

References:

• Filtering Specific Domains (FQDN/URLs)
• FQDN Filtering

According to the VMware NSX Documentation, this is the NSX feature that can be leveraged to achieve consistent policy configuration and simplicity across sites:

• NSX Federation: This feature allows you to create and manage a global network infrastructure that spans across multiple sites using a single pane of glass. You can use this feature to synchronize policies, segments, gateways, firewalls, VPNs, load balancers, and other network services across sites.

According to the VMware NSX Documentation, these are two of the use cases for Distributed Intrusion Detection, which is a feature of NSX Network Detection and Response:

• Quarantine workloads based on vulnerabilities: You can use Distributed Intrusion Detection to detect vulnerabilities in your workloads and apply quarantine actions to isolate them from the network until they are remediated.
• Identify security vulnerabilities in the workloads: You can use Distributed Intrusion Detection to scan your workloads for known vulnerabilities and generate reports that show the severity, impact, and remediation steps for each vulnerability.

https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.2/administration/GUID-53D6C480-7AD3-4B23-922D-430C89992B57.html

In VMware NSX 4.x, the Tier-0 gateway serves as a critical component for North-South traffic management, which refers to the traffic entering and exiting the data center. It essentially acts as a bridge between the external networks and the internal NSX-T Data Center environment.

The Tier-0 gateway is designed to handle various functionalities including routing, NAT, and firewalling, making it an effective point for network introspection. Network introspection at the Tier-0 gateway allows administrators to monitor, manage, and secure the traffic as it flows between different networks, including the traffic headed to and from the internet or other external networks.

Here's why other options are less appropriate:

• A. Guest VM vNIC: This refers to the virtual network interface cards attached to virtual machines. While they handle East-West traffic (traffic within the data center), they are not typically used for North-South traffic introspection.
• B. Partner SVM: Service Virtual Machines (SVMs) provided by third-party vendors can integrate with NSX for various services like security, but they are not the direct insertion points for North-South traffic introspection.
• D. Host Physical NIC: These are the network interface cards on the physical hosts. Although they are involved in the underlying transport of North-South traffic, they do not serve as insertion points for introspection in the context of NSX.

By utilizing the Tier-0 gateway for North-South introspection, organizations can achieve a centralized and efficient approach to traffic management and security at the entry/exit points of the network.

References:

• VMware NSX-T Data Center documentation provides detailed explanations of gateway functionalities and their roles in network introspection.
• VMware NSX-T Architecture and Component guides detail the use of Tier-0 and Tier-1 gateways in traffic management and security implementations.

The four types of role-based access control (RBAC) permissions are Read, None, Full access, and Execute1. Read permission allows the user to view the configuration and status of the system. None permission denies any access to the system. Full access permission grants all permissions including Create, Read, Update, and Delete (CRUD). Execute permission includes Read and Update permissions1. Auditor, Enterprise Admin, and Network Admin are not types of permissions, but types of roles that have different sets of permissions. References: NSX Features

There are four types of permissions. Included in the list are the abbreviations for the permissions that are used in the Roles and Permissions and Roles and Permissions for Manager Mode tables.

• Full access (FA) - All permissions including Create, Read, Update, and Delete
• Execute (E) - Includes Read and Update
• Read (R)
• None

NSX-T Data Center has the following built-in roles. Role names in the UI can be different in the API. In NSX-T Data Center, if you have permission, you can clone an existing role, add a new role, edit newly created roles, or delete newly created roles.

Role-Based Access Control (vmware.com)

The answer is A. SR is instantiated and automatically connected with DR.

SR stands for Service Router and DR stands for Distributed Router. They are components of the NSX Edge node that provide different functions1

The SR is responsible for providing stateful services such as NAT, firewall, load balancing, VPN, and DHCP. The DR is responsible for providing distributed routing and switching between logical segments and the physical network1

When a stateful service is enabled for the first time on a Tier-0 Gateway, the NSX Edge node automatically creates an SR instance and connects it with the existing DR instance. This allows the stateful service to be applied to the traffic that passes through the SR before reaching the DR2

According to the VMware NSX 4.x Professional Exam Guide, understanding the SR and DR components and their functions is one of the exam objectives3

To learn more about the SR and DR components and how they work on the NSX Edge node, you can refer to the following resources:

• VMware NSX Documentation: NSX Edge Components 1
• VMware NSX 4.x Professional: NSX Edge Architecture
• VMware NSX 4.x Professional: NSX Edge Routing

https://docs.vmware.com/en/VMware-NSX-T-Data-Center/3.2/administration/GUID-EAAD1FBE-F750-4A5A-A3BF-92B1E7D016FE.html

• Route Aggregation and and D) BGP neighbours are available when configuring BGP in a VRF. "Route distribution" does not exist, what you can do is a "Route Re-Distribution" via BGP. https://docs.vmware.com/en/VMware-NSX/4.1/administration/GUID-4CB5796A-1CED-4F0E-ADE0-72BF7B3F762C.html
