301a BIG-IP LTM Specialist: Architect, Setup, and Deploy (301a) Questions and Answers

Questions 4

Import guest upgrade images to both vCMP hosts

An LTM Specialist must upgrade a vCMP Guest Active/Standby LTM pair from version 11.3 to 11.5.3 on two vCMP hosts. Where should the LTM Specialist import the 11.5.3 ISO images? (Choose one answer.)

Options:

A.

To both vCMP hosts

B.

To the primary vCMP host and the active guest instance

C.

To the secondary vCMP host and the standby guest instance

D.

To the vCMP guest instances

Buy Now
Questions 5

An TLM Specialist needs to configure a virtual server to terminate SSL connection on the LTM device.

Cryptographic information must be re-authorized for SSL sessions that remain open for longer than 30 seconds.

Which settings should the LTM Specialist configure in the client SSL profile?

Options:

A.

set the Handshake Timeout to 30 seconds

B.

enable Require Peer SN1 Support

C.

set the Renegotiate Period to 30 seconds

D.

set the Renegotiate Max Record Delay to 30

Buy Now
Questions 6

High CPU with connection mirroring

A BIG-IP LTM device is configured for many HTTP virtual servers. The LTM Specialist notices significant degradation of CPU performance. Which setting should the LTM Specialist modify to mitigate this concern? (Choose one answer.)

Options:

A.

Source Address Persistence

B.

Connection Limit

C.

SNAT

D.

Connection Mirroring

Buy Now
Questions 7

An LTM Specialist needs to upgrade all guests on a Viprion eight CMP guests.

What is the maximum number of guests that the LTM Specialist should upgrade at once?

Options:

A.

Eight

B.

One

C.

TWO

D.

Four

Explanation

Each guest is independent, just like hardware upgrades. Can only upgrade one by one, there is no way to upgrade at the same time.

Buy Now
Questions 8

An application is being load balanced through the LTM device using the configuration displayed below.

The network has been re-engineered to NAT all client connection. As a result, all client connections are hitting the same pool member.

Which changes should the LTM Specialist make in order to restore load balancing functionality wile maintaining session persistence?

Options:

A.

Change the virtual server type to Standard, add an http profile, and change the persistence profile to Destination Address

B.

Leave the virtual server type set Performance (Layer 4) and change the persistence type to hash

C.

Change the virtual serer type to Forwarding (Layer 4) and leave the persistence type to hash source Address

D.

Change the virtual server to Standard add an http profile, and change the persistence profile to Cookie persistence

Buy Now
Questions 9

An LTM device receives a response string containing " error "

Which monitor type and parameter will mark the HTTP server as down?

Options:

A.

HTTP monitor, Receive String " error " , and set the Reverse option to Yes

B.

HTTP monitor and Receive String " error ' ' ... flag is up

C.

HTTP monitor. Receive String " down " , and set the Reverse option to Yes .... flag is

D.

HTTP monitor and Receive Disable String " error ' ' .... flag is disable

Buy Now
Questions 10

An LTM Specialist needs to configures virtual server that uses PVA or OPVA Which virtual server type should be used?

Options:

A.

Stateless

B.

Performance (HTTP)

C.

Standard

D.

Performance (Layer 4)

Buy Now
Questions 11

An LTM Specialist plans to enable connection mirroring for a virtual server in an HA environment.

What must the LTM Specialist consider before implementing the configuration change?

Options:

A.

Impact on system performance that might be noticeable

B.

The add-on license that is required for this feature to be available

C.

Creating the required separate interface for connection mirroring

D.

Decreased number of possible concurrent connections to that virtual server

Connection mirroring will bring performance consumption

Buy Now
Questions 12

An LTM Specialist discovers an issue with the custom http monitor that returns in a false positive status.

The end users cannot get the right website, but the http monitor marks the pool member UP.

What is causing the false positive result?

Options:

A.

The end user should use another type of browser.

B.

The response is chunked.

C.

The response is compressed.

D.

The Content-Type has value " iso-8859-200 " .

Buy Now
Questions 13

Exhibit.

The three VLANS shown provide connectivity to backend servers. The backend servers are being moved to unmanaged switches and require separate interfaces.

How should the F5 device interfaces be configured?

Options:

A.

Create a Trunk interface and combined interface 1.1.1.2 and 1.3.

B.

Create a Trunk interface and select VLAN„A, VLAN_B. and VLAN_C.

C.

Create VLAN named VLAN_A enter 100 under Tag and move interface 1.1 to tagged Create VLAN_B enter 200 and move interface 1.2 to tagged Create VLAN_C Center 300 and move interface 1.3 to tagged.

D.

Create VLAN_A move interface 1.1 to untagged. Create VLAN_B move interface 1.2 to untagged. Create VLAN_C move interface 1.3 to untagged.

Buy Now
Questions 14

An LTM Specialist needs to terminate client SSL traffic and based on the cookie presented by client.

Which set of profiles should the LTM Specialist use?

Options:

A.

HTTPS, Client SSL, Cookie Persistence Profile

B.

HTTP, Server SSL, SSL Cookie Profile

C.

HTTPS, Server SSL, SSL Cookie Profile

D.

HTTP, Client SSL, Cookie Persistence Profile,

Buy Now
Questions 15

HA group external trunk failure threshold

A design requires the LTM device to become HA Standby when one of the two physical interfaces on the External trunk is down. The External trunk is an interface on the External VLAN. Which TMOS command enables this behaviour? (Choose one answer.)

Options:

A.

tmsh create sys ha-group External trunks add { External }

B.

tmsh modify net vlan External failsafe enabled

C.

tmsh create sys ha-group External trunks add { External attribute percent-up-members 100 }

D.

tmsh create sys ha-group External trunks add { External threshold 2 weight 101 }

Buy Now
Questions 16

Refer to the following iRule:

What is a complete list of profiles that must be applied to the virtual server for this iRule?

Options:

A.

Fast L4, HTTP

B.

TCP, HTTP

C.

TCP, HTTP, Client SSL

D.

Fast L4 , HTTP, Stream

Buy Now
Questions 17

What should the LT ' M Specialist add to the virtual server?

Options:

A.

one Stream profile and an iRule with the command of STREAM expression (@http:// @https:// @@internalapp@publicapp@)

B.

two Stream profiles and an iRule with the command of STREAM expression (@http:// @https:// @@internalapp@publicapp@)

C.

one Stream profile with the expression of @http:// @https:// @

D.

Two Stream profiles, one profile for each rewrite requirement

Buy Now
Questions 18

An LTM Specialist needs to configure a virtual server with the requirements displayed below.

Application is currently an internal HTTP application

Encrypted external user access

Links are hard for siteA example.com and need to rewritten to siteB.Example.com

Which profiles must the LTM Specialist use to provide the proper functionality?

Options:

A.

Clientssll, Stream

B.

Serverless, Stream

C.

Clientssl, fastL4, Stream

D.

Serverless, fastL4, Stream

For http application and external encryption, clientssl is required, and if the message content needs to be modified, the steam profile is required. FastL4 profile cannot coexist with clientssl and stream.

Buy Now
Questions 19

An HTTP monitor is created and assigned to a pool with the following non-default configuration:

Interval: 7 seconds

Timeout: 22 seconds

Reverse: Yes

Send String: GET/status.html HTTP/1.1/r/nHost:test.example.com/r/nConnector:Close Receive String: Up

The HTTP server sends the following response:

What is the resulting pool status?

Options:

A.

Unavailable (Enabled)

Available (Enabled)

B.

Offline (Enabled)

C.

Unknown (Disabled)

Buy Now
Questions 20

vCMP host HD1.2 upgrade

An LTM Specialist is completing an upgrade of a vCMP host to BIG-IP version 14.1. The system hosts a vCMP guest. The following software volumes are installed on the vCMP host:

Volume

Product

Version

Build

Active

Status

HD1.1

BIG-IP

13.1.3.2

0.0.4

Yes

Complete

HD1.2

BIG-IP

14.1.0.0

0.0.4

No

Complete

What is the supported method to complete this task? (Choose one answer.)

Options:

A.

On the vCMP guest, select HD1.2 in System > Software Management > Boot Locations; choose Yes to install configuration; select Activate.

B.

On the vCMP host, set the vCMP guest to Configured in vCMP > Guest List; activate HD1.2 through System > Software Management > Boot Locations.

C.

On the vCMP host, select HD1.2 in System > Software Management > Boot Locations; choose Yes to install configuration; select Activate.

D.

On the vCMP host, set the vCMP guest to Deployed in vCMP > Guest List; activate HD1.2 through System > Software Management > Boot Locations.

Buy Now
Questions 21

Which process can be eliminated by terminating SSL communication on the LTM device rather than the backend pool members?

Options:

A.

generating CSRS

B.

obtaining SSL certificates from a certificate authority

C.

administering SSL on the web servers

D.

applying security patches on the backend pool members

Buy Now
Questions 22

Two LTM devices must be manually configured to restrict in the same Device Group.

What is the correct order of steps to meet this requirement?

Options:

A.

Configure VLAN, Configure-Sync IP, Configure Failover type, Establish Device Trust, Sync Device Trust, Create type, Establish Device Sync Device Trust, Create Device Group.

B.

Configure VLAN, Configure Self-IPs, Configure Config-Sync IP. Configure Failover type, Establish Device Trust, Sync Device Trust, Create Device Group.

C.

Configure Self-IPs, Configure VLAN, Configure Config-Sync IP. Configure Failover type, Establish Device Trust, Sync Device Trust, Create Device Group

D.

Configure VLAN, Configure Config-Sync IP. Configure Self-IPs. Configure Failover type. Establish Device Trust, Create Device Group

Buy Now
Questions 23

An unwanted IP address tries to connect to the configuration utility via Self IP An LTM Specialist needs to block the attempts based on the IP address.

How should the LTM Specialist block the attempts without affecting other users?

Options:

A.

SSH IP allow list

B.

Port lockdown

C.

Device trust

D.

Packet filter

Buy Now
Questions 24

Two-tier web/database direct responses

An LTM Specialist needs to configure VS_HTTP and VS_DB for an online shopping site. VS_HTTP passes client requests to web servers. The web servers query database servers through VS_DB. Initially the database servers return packets directly to the web servers. Which setting must be enabled for this configuration to function correctly? (Choose one answer.)

Options:

A.

VS_DB Auto Last Hop

B.

VS_DB SNAT Automap

C.

VS_HTTP SNAT Automap

D.

VS_HTTP Auto Last Hop

Buy Now
Questions 25

Refer to the exhibit.

The pool shown is configured with four pool members in a variety of states. The application is receiving a large number of request. The LTM Specialist needs to make changes to make sure that all members receive the same levels of traffic.

Which changes need to be made?

Options:

A.

Enable 10.80.1.40 disable priority group activation, enable ratio

B.

Enable 10.80.1.40 and 10.80.1.1.20 disable group activation, enable Round Robin

C.

Enable 10.80.1.20 disable priority group activation, enable Round Robin

D.

Enable 10.80.1.40 and 10.80.1.20 disable priority group activation, enable ratio.

Buy Now
Questions 26

A VCMP guest has the following characteristics:

• Resources allocated for CPU memory, network interfaces, and disk space

• Virtual disk created

• The guest is NOT running

The guest is NOT running in which state is the VCMP guest

Options:

A.

Offline

B.

Deployed

C.

Provisioned

D.

Configured

Buy Now
Questions 27

An LTM Specialist needs to load balance an application using an LTM device to meet the requirements:

The application servers do NOT Support SSL, but client access to the application should be secured.

Multiple requests from the same client should be sent to the same pool member.

All pool members will have roughly the same processing power, and traffic should be distributed evenly.

The LTM device is NOT the pool members ' default gateway.

which configuration should the LTM Specialist.

Options:

A.

a performance L4 virtual server with a SNAT and cookie persistence

B.

a performance L4 virtual server with a Client SSL profile and Source Address persistence

C.

A performance L4 virtual server with a SNAT, HTTP profile. Server SSL profile, and cookie persistence

D.

A standard virtual server with a SNAT, HTTP profile Server SSL profile, and cookie persistence

E.

A standard virtual server with a SNAT, HTTP profile, Client profile, andd cookie persistance.

Buy Now
Questions 28

New remote syslog via TMSH

The network team has recently added a new syslog server with IP address 10.1.1.12. Which command adds the new syslog entry on the F5 LTM device? (Choose one answer.)

Options:

A.

`tmsh modify sys syslog remote-servers add { server { host 10.1.1.1 remote-port 514 } } save sys config`

B.

`tmsh adjust sys syslog remote-servers add { server { host 10.1.1.1 remote-port 514 } } save sys config`

C.

`tmsh add sys syslog remote-servers add { server { host 10.1.1.1 remote-port 514 } } save sys config`

D.

`tmsh create sys syslog remote-servers add { server { host 10.1.1.1 remote-port 514 } } save sys config`

Buy Now
Questions 29

An LTM Specialist must reconfigure a BIG-IP LTM system that load balances traffic to web application servers. The application developer inform the LTM Specialist that TLS must be used to communicate

with the application servers.

Which additional profile is required as part of virtual server configuration?

Options:

A.

SPDV profile

B.

Server SSL

C.

Client SSL

D.

Rewrite profile

Buy Now
Questions 30

A BIG-IP device delivers the online shopping website https://shop.example.com. Two pool members handle the traffic. An iRule directs requests with the hip parameter " environment=development " to a third pool member for a staging environment.

Which combination of profiles is needed at minimum?

Options:

A.

tcp, http, request logging

B.

tcp, http, clientssl

C.

tcp, clientssl, serverssl

D.

http, clientssl, persistence

Buy Now
Questions 31

An LTM Specialist is removing some of the load off an existing cluster by adding a adding a third BIG-IP

device to the device group. The new device can deliver twice the performance of the other two devices.

The LTM Specialist needs to make sure that the BIG-IP device with the highest available capacity is

always selected to take over a traffic group in the event of a failover.

Which failover method is most appropriate?

Options:

A.

Ordered List

B.

Load Aware

C.

HA Group

D.

HA Capacity

Buy Now
Questions 32

One LTM device in an HA pair of LTM devices is unable to reach its default gateway. An HA Failover event needs to happen.

Which configuration item enables this behavior?

Options:

A.

iRule

B.

Gateway Fail Safe

C.

Gateway pool monitor

D.

Gateway pool

Buy Now
Questions 33

AVR website statistics

An LTM Specialist needs to gather website statistics such as latency and throughput on an existing virtual server that load balances backend web servers. Which F5 feature provides this? (Choose one answer.)

Options:

A.

The Statistics panel

B.

The Performance panel

C.

The AVR module

D.

The Dashboard

Buy Now
Questions 34

The web application team requests help from the LTM Specialist to Improve the performance of their web sites that are load balanced by the BIG-IP LTM device with a Standard Virtual Server.

Which virtual server type will improve the performance of the web application servers?

Options:

A.

Performance (HTTP)

B.

Performance (Layer 4)

C.

Stateless

D.

Forwarding (IP)

Buy Now
Questions 35

A virtual server configuration for traffic destined to a server is as shown:

FTP traffic is destined to the 192.168.1.101 server from the source of 192.168.2.129.

Based on precedence, which virtual server accepts this traffic?

Options:

A.

MyVS4

B.

MyV53

C.

MyVS1

D.

MyVS2

Buy Now
Questions 36

An LTM Specialist observes decreased performance and intermittent connection reap LTM system.

Based on the configuration, which action will address these issues?

Options:

A.

Use an optimized TCP profile.

B.

Use a FastL4 profile on the virtual server

C.

Use a default caching profile on the virtual server.

D.

Use a shorter idle timeout on the TCP profile.

Buy Now
Questions 37

Geolocation iRule on SSL website

An LTM Specialist deploys an iRule designed to determine the country of origin of an incoming client connection. The iRule is used with an SSL-enabled web application. Which profile is required for the iRule to function properly? (Choose one answer.)

Options:

A.

DNS

B.

TCP

C.

UDP

D.

HTTP

Buy Now
Questions 38

An application is sensitive to packet loss and unexpected session termination. A pair of LTM devices is configured in an Active/Standby high availability configuration. SNATS are NOT used and the virtual server contains a Universal Persistence profile.

which two actions must an LTM Specialist take to ensure the sessions are maintained between the client and server during an LTM device failover event while maintaining maximum uptime? (Choose two.)

Options:

A.

configure a serial failover cable for mirror traffic

B.

configure a OneConnect profile to mirror connections

C.

configure a VLAN and primary mirroring address for mirror traffic

D.

enable Mirroring for a virtual server and persistence profile

E.

enable Clone Pools for a virtual server and a persistence profile

Buy Now
Questions 39

High-connection-count SNAT configuration

An application is expected to maintain more than 100,000 concurrent TCP connections to a single pool member. What is an appropriate SNAT configuration in this situation? (Choose one answer.)

Options:

A.

SNAT Automap enabled

B.

A SNAT pool with 4 IP addresses

C.

A SNAT pool with 1 IP address

D.

A static SNAT

Buy Now
Questions 40

Three-service session affinity

An application contains three services fronted by a BIG-IP device: Login on TCP/8443, Matching on TCP/5523, and Purchase on TCP/443. Application performance greatly improves if the same pool member handles all three services for a client. Each virtual server currently uses Source Address Affinity persistence. Which option should an LTM Specialist configure to maximize performance? (Choose one answer.)

Options:

A.

Priority Group Activation

B.

Fallback Persistence

C.

Match Across Services

D.

Match Across Virtual Servers

Buy Now
Questions 41

AN LTM Specialist needs to determine the delay between an LTM device and the internal web server for a specific client.

Which two AVR reporting options should the LTM Specialist enable to measure the delay? (Choose two.)

Options:

A.

User agents

B.

Methods

C.

Response codes

D.

Server latency

E.

Client IP

The problem is to specify the server delay of the client

Buy Now
Questions 42

An LTM Specialist needs to apply SNAT using currently used SNAT pool to a new virtual server.

What needs to be completed before applying that configuration change?

Options:

A.

Review connection for the selected SNAT pool and enlarge it if appropriate

B.

Make sure that the BIG-IP device is NOT operating under heavy load during peak times

C.

Verify that the IP address of the SNAT pool are in the same subnet as the pool members

D.

Verify that the IP address of the SNAT pool are in the same VLAN as the pool members.

SNAT does not need to in the same vlan or same network segment as the pool member, as long as the route is reachable , excluding C and D he connection information of the SNAT pool to avoid port exhaustion under high concurrency

Buy Now
Questions 43

An LTM device needs an additional traffic group.

Which configuration item is required?

Options:

A.

Default device

B.

Group name

C.

MAC Masquerade Address

D.

Auto Fallback Timeout

Buy Now
Questions 44

Outbound SNAT pool of addresses

An LTM Specialist needs to use a set of addresses to access an Internet website in an outbound configuration. Which feature should be configured? (Choose one answer.)

Options:

A.

NAT address

B.

SNAT pool

C.

SNAT address

D.

NAT pool

Buy Now
Questions 45

An LTM Specialist needs to use a set of addresses to access an Internet website in an outbound configuration.

Which feature should the LTM Specialist configure?

Options:

A.

NAT pool

B.

NAT address

C.

SNAT pool

D.

SNAT address

Buy Now
Questions 46

To improve application security, an LTM Specialist must configure a BIG application access. The BIG-IP system to authenticate the client certificate before permitting application access. The BIG-IP system must also support the ability to red to redirect users to a certificate enrolment system without generating a browser error.

Within the Client SSL profile, which value should the LTM Specialist select for the Client Certificate option?

Options:

A.

Require

B.

Request

C.

Demand

D.

ignore

Buy Now
Questions 47

An LTM Specialist is configuring a new virtual server on an LTM device and assigning a SNAT pool that is already is use another virtual server. Both virtual servers use the same pool members to load balance traffic. A maximum of 35,000 users needs to be able to access each virtual server ta any time. The network architecture does NOT allow the backend servers to use the LTM device as a default gateway.

What is the minimum number of SNAT addresses required in the SNAT pool to meet the needs of the virtual servers?

Options:

A.

2

B.

3

C.

4

D.

1

Both vs share the same snat pool, and both use the same pool member. Then the concurrent number of snatpool will be added. For each VS, there is a maximum of 35,000 users, and those two VSs have a maximum of 70,000 users. The stem did not mention how many connections each user would have concurrently. Calculated with a minimum of 1 connection, then 70,000 connections would be concurrent. One IP can support 65,535 connection. Therefo

Buy Now
Questions 48

What should an LTM Specialist configure on an LTM device to send AVR notification emails?

Options:

A.

Email notification to be sent via iControl from the LTM device

B.

Syslog on the LTM device to send to an SMTP server

C.

Custom SNMP traps on the LTM device for AVR notifications

D.

Email notification to be sent via SMTP from the LTM device

Buy Now
Questions 49

An LTM Specialist must create a new virtual server for HTTP access. The LTM Specialist creates a forwarding virtual server to reach the resource.

What is a potential result of this action?

Options:

A.

IP conflict result

B.

HTTP traffic is NOT allowed

C.

Other service ports could be allowed

D.

Packet filter allowances are also required

Buy Now
Questions 50

A Client makes the request displayed below to the application server.

Which virtual server type should an LTM Specialist use to load balance based on the URI?

Options:

A.

Forwarding (Layer 2)

B.

Stateless

C.

Standard

D.

Performance (Layer 4)

Buy Now
Questions 51

The network team introduces a new subnet 10.10.22.0/24 to the network. The route needs to be configured on the F5 device to access this network via the 30.30.30.158 gateway.

How should the LTM Specialist configure this route?

Options:

A.

Tmsh modify net route 10.10.22/24 gw 30.30.30.158

B.

Tmsh create net route 10.10.22/24 gw 30.30.30.158

C.

Tmsh changey net route 10.10.22/24 gw 30.30.30.158

D.

Tmsh add net route 10.10.22/24 gw 30.30.30.158

Buy Now
Questions 52

An LTM device is configured with these wildcard virtual servers:

VS_HTTP_WILDCARD: 0.0.0.0/0, port 80

VS_HTTPS_WILDCARD: 0.0.0.0/0, port 443

VS_172_24_1_WILDCARD: 172.24.1.0/24, any port

VS_172_24_WILDCARD: 172.24.0.0/16, any port

Which virtual server will process the traffic? (Choose one answer.)

Options:

A.

VS_172_24_1_WILDCARD

B.

VS_HTTP_WILDCARD

C.

VS_172_24_WILDCARD

D.

VS_HTTPS_WILDCARD

Buy Now
Questions 53

Exhibit.

The server team has recently configured the three new DNS servers shown for the data center. No current DNS servers are currently configured on the LTM device.

Which command should be used to configure the LTM device to use the new DNS servers?

Options:

A.

tmsh create/systins name-servers add {192 168.1.2.192.168.100.1O0.192.168.2O0.2OO}

B.

tmsh change /sysdns name-servers add {192.168.1.2.192.168.100.100.192.168.200.200}

C.

tmsh modify/sysdns name-servers add {192.168.1.2.192.168.100.100.192.168.200.200}

D.

tmsh set/sysdns name-servers add {192.168.2.192.168.100.100.192.168.200.200}

Modify the configuration with modify, and create the configuration with create. Excluding B and D, and the question is to modify the DNS pointer of E5 itself the need to use is modify.

Buy Now
Questions 54

AN LTM Specialist is using an external monitor evaluate the hard drive usage of a node. The monitor has marked the node down because it exceeded the specific threshold. The disk usage on the server has been corrected below the threshold, however, the node remains offline.

Which feature is causing this problem?

Options:

A.

The parameter Time Until UP has a value greater than 0

B.

The value of Manual Resume is set to No

C.

The value for UP interval is enable with a value greater than 0

D.

The value for Manual Resume is set to Yes

Buy Now
Questions 55

An LTM Specialist configures a new virtual server with a single pool member. The LTM Specialist has NOT defined a health monitor for the pool, pool member or node.

What is the status of the virtual server?

Options:

A.

Available (Enabled)

B.

Offline (Disabled)

C.

Unavailable (Enabled)

D.

Unknown (Enabled)

Buy Now
Questions 56

Where does a LTM Specialist view all of the objects that are part of a deployed iApp?

Options:

A.

iAPP > Application Policy > Objects

B.

Local Traffic . Virtual Servers > Applications

C.

IAP > Application Service > Components

D.

Local Traffic > Network Map > View Map

Buy Now
Exam Code: 301a
Exam Name: BIG-IP LTM Specialist: Architect, Setup, and Deploy (301a)
Last Update: Nov 20, 2026
Questions: 189
301a pdf

301a PDF

$22.5  $89.99
301a Engine

301a Testing Engine

$28.75  $114.99
301a PDF + Engine

301a PDF + Testing Engine

$35  $139.99
